E-bike\/ elektrokolo
- Baterie
- 840Wh battery
- UI/Dálkové ovládání
- Mastermind TCU, 2.2" high resolution screen, fully customizeable with Specialized app, works with Apple Find My
- Motor
- Specialized 3.1 Motor, 101Nm torque, 666W power
- Nabíječka
- Specialized 4amp charger
Rámová sada
- Sedlová objímka
- Alloy, 38.6mm
- Rám
- FACT 11m Carbon, SWAT downtube storage, 12x148mm UDH compatible rear dropout, side entry battery, adjustable geometry, 130mm of travel
- Vidlice
- FOX 36 SL Performance Elite, GRIP X Damper, HSC, LSC, LSR adjust, 140mm travel, 44mm offset, 15x110mm
Odpružení
- Zadní tlumič
- FOX FLOAT Performance Elite GENIE, Ride Dynamics Developed, 2-position compression adjust, 190x45mm
Brzdy
- Přední brzda
- SRAM Motive Bronze, 4-piston caliper, hydraulic disc, 200mm rotor
- Zadní brzda
- SRAM Motive Bronze, 4-piston caliper, hydraulic disc, 200mm rotor
Pohon
- Převodníky
- SRAM 34t T-Type chainring, 104 BCD, steel
- Páčky řazení
- SRAM AXS POD Controller
- Kliky
- SRAM GX Alloy Crank, ISIS interface, 55mm chainline, 160mm
- Přehazovačka
- SRAM GX Eagle AXS Transmission
- Řetěz
- SRAM GX Eagle Transmission 12-Speed Flattop Chain
- Kazeta
- SRAM GX Transmission, XS 1275, 10-52t
Zapletená kola
- Zadní kolo
- Roval Traverse SL II Rim, hookless carbon, 30mm inner width, tubeless ready, 29", Industry 9 1/1 Hub, 12x148mm, 32H, Sapim D-Light Spokes
- Přední kolo
- Roval Traverse SL II Rim, hookless carbon, 30mm inner width, tubeless ready, 29", Industry 9 1/1 Hub, 15x110mm, 28H, Sapim D-Light Spokes
- Přední plášť
- Specialized Purgatory, GRID Casing, T9 Compound, 29x2.4
- Zadní plášť
- Specialized Purgatory, Grid Trail Casing, T7 Compound, 29x2.4 (S1 27.5x2.4)
- Duše
- Standard, Presta Valve
Kokpit
- Představec
- Alloy Trail Stem, 35mm bar bore
- Sedlo
- Body Geometry Power Comp, steel rails
- Řídítka
- Specialized Alloy, 30mm/40mm rise, 35mm, 800mm wide
- Gripy
- Specialized Trail Grips
- Sedlovka
- X-Fusion Manic, 34.9, S1-S2: 125mm, S3: 150mm, S4: 170mm, S5-S6: 190mm Travel, 0mm offset
Doplňky
- SWAT
- SWAT internal downtube storage
Hmotnost
- Hmotnost
- 21.76 kg (47 lb, 15.6 oz)
- ID produktu
- 293744
Podrobnosti o produktu
- Prohlášení o shodě
- As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS.
For information on lithium-ion battery standards and regulations in New York City, visit: [www.nyc.gov/fdny/batteries](https://www.nyc.gov/fdny/batteries)
Hmotnost
- Hmotnost ve velikosti
- S3
-
Geometrie
S1 - 27.5 S2 - 29 S3 - 29 S4 - 29 S5 - 29 S6 - 29 160 160 160 160 160 160 800 800 800 800 800 800 50 50 50 50 50 50 155 155 143 143 143 143 125 125 150 170 190 190 Stack 602 607 616 630 644 657 Reach 400 420 450 475 500 525 Head-Tube Length 95 100 110 125 140 155 Head-Tube Angle 64.8 65 65 65 65 65 B-B Height (low) 339 339 339 339 339 339 B-B Drop 36 36 36 36 36 36 Trail 128 126 126 126 126 126 Fork Length (full) 550 550 550 550 550 550 Fork Rake/Offset 44 44 44 44 44 44 Front Center 716 736 770 801 833 863 Chain-Stay length 447 447 447 447 447 447 Wheelbase 1160 1181 1215 1246 1277 1309 Top-Tube Length (horizontal) 539 560 592 620 649 677 Bike Stand-Over Height 761 763 773 783 793 803 Seat-Tube Length 375 385 405 425 445 465 Seat-Tube Angle 77 77 77 77 77 77 Seat Post Max Insertion 292 312 210 227 249 271 Seat Post Min Insertion 80 80 80 80 80 80 Saddle Height for Effective ST Angle 645 690 735 780 825 870
